KKS 400 U
Semi-automatic mitre saw
Workspace [mm]: 130
Benefits at a glance
- Clamping, sawing, reverse motion, opening – touch of a button
- Push-button adjustment of the cutting height
- User-friendly electronic control directly on the machine
- Space saving installation
- No manual presetting of the vertical clamp
- Two cutting speeds for virtually all applications
- Operation
- Easy and fast operation via push-button
Display- Digital display of cutting angle
Visual feed control- Visual feed control (optional)
- For machining thick-walled pipes and solid material
Workpiece clamping- Hydraulic long stroke vertical vice
- Large scale pressure piece for secure clamping on both sides of the saw blade
Additional workpiece clamping- Horizontal clamping device to the right and left of the saw blade
- Clamping aid for thin-walled profiles
- Additional clamping for example sawing of acute angles
Precise straight and mitre cuts- Stable contact surface for precise cuts
- Adjustable forwards and backwards
Rotary table for mitre cuts- Easy, manual adjustment
- Pivoting range 180°
Individual feed adjustment- Universal, infinitely-variable adjustment, even during the sawing process
- Lower feed rate with stainless steels, higher feed rate for tubes
- Feed movement via hydraulic cylinder
Minimum quantity lubrication- Virtually dry workpiece
- Optimum tool lubrication
- Can be installed in addition to floot coolant device
- Disposal of lubricant unnecessary
- Long blade life
Precise cuts- Robust, powerful drive with hardened and ground helical gears
- Smooth operation
Material related cutting speed- Adaptable to the material
- Two cutting speeds as standard
Infinitely-variable adjustment of cutting speed- Toothed-belt drive and frequency regulator for infinitely-variable cutting speed (opt.)
- Optimum adjustment of cutting speed to material quality
- Long blade life
- L 45 E length measuring device
- For manually adjustment of measurement length
- Adjustable vernier for high measurement accuracy
- Attachable stop guide for short cut lengths
- Stop arm can be pivoted upwards
- Can be fitted with a digital display
L 45 I length measuring device- The stop is moved using handwheel, clamping hydraulically using hand valve
- Digital length display
- Stop arm can be swiveled up and down
L 41 NC length measuring device- For electronic adjustment of the measuring length via NC-control
- Feed gripper is clamped automatically after the positioning
- Easy operation via touch screen
- Data import via USB
T3 Transport System for Circular Saws- For material feed and removal with circular saws
- Ball-bearing light-running rollers
- Operating width: 330 mm / Roller diameter: 60 mm
- KKS 450 U
Semi-automatic mitre saw especially suitable for single cuts and processing of small batches.
KKS 450 HSemi-automatic mitre saw suitable for almost all steel qualities and for single cuts and processing small batches.
