Kaltenbach

KF 2607 E

PLATE CUTTING AND DRILLING CENTRE

Plate Processing Centre
Capacity range W x L [mm]: 2600 x 6000

Benefits at a glance

  • Diverse manufacturing technologies such as drilling, countersinking, thread-cutting, contourmarking, oxyfuel or plasma cutting
  • Powerful drives for optimum performance and low production times
  • 7-place tool changer for faster setup times
  • Less space needed for measuring carriage
  • Increased traversing speed of axes
  • Durable construction provides the basis for a long-term investment
  • Common cut for less waste









Alternative Machines

KF 2607 E
Convenient Operation of the System

Convenient Operation of the System

  • Plain-text display of machine data and possible error messages
  • Good observation of the processes and rapid intervention in case of disturbance
Low Wear and Low Maintenance

Low Wear and Low Maintenance

  • Drill carriage mounted on dual play-free, pre-stressed linear guides
  • Robust mountig for high precision when drilling
Universal, Economical Gas Cutting Process

Universal, Economical Gas Cutting Process

  • Universally implementable gas cutting unit built onto the drilling unit
  • Automatic height adjustment of the cutting unit
High Cutting Speed

High Cutting Speed

  • Highest cutting performance and optimum cutting quality
  • In addition to autogenous gas cutting, a high-performance plasma cutting machine can optionally be used
  • Common cut and cross-cut technology generates significantly less waste
Dust Free Work Environment

Dust Free Work Environment

  • System with pre-separator and dust collection container
  • Filtering unit with eight cartridges in flame retardant design
  • Automatic filter cleaning
Material Marking by Means of a Milling Tool on the Drill Head

Material Marking by Means of a Milling Tool on the Drill Head

  • Application of numbers and letters as well as reference boundaries for welding add-on pieces
  • DSTV-Data import
  • Use of high-speed carbide tools
Machine Operation with the Most Up-to-Date Software

Machine Operation with the Most Up-to-Date Software

  • Easy data import and export
  • Automatic or manual nesting
  • Partial programming possibility via NC-DSTV, DXF or DWG files, integrated drawing program or macros
  • And much more
Dimensions (L x W x H)mm15500 x 9000 x 5000
Weightkgapprox. 13000
ProceduresDrilling
Thermal cutting
Contour Marking
Milling
Threading
Reducing
Signing
Rapid advance/return movementmm/min0
Drilling unit horizontal (Z- and W-axis)Pieces1
Drill Sizemm6,8 - 50
Number of tools per axisPieces7
Drive power axekW34,5 kW
Spindle speed max.min-13500
Sheet starting material sheet widthmm220 - 2600
Sheet starting material sheet lengthmm500 - 6000
Sheet starting material sheet thicknessmm6 - 100
Toolchanger x Magazine placesPieces1 x 7
ToolsCarbide Tools
HSS-Tools
Solid Carbide Tools
MaterialclassSawing
ProcessPlate
